SYF 504
| SKU | SYF 504 |
|---|---|
| Product Type | Pillow Block for Insert Bearings |
| Brand | SKF |
| Seat Diameter | 47mm |
| Centre Height | 33.3mm |
| Bolt Centres | 50.8mm |
| Number of Bolts | 2 |
| Housing Material | Cast iron |
Short base pillow (plummer) block housings are designed to accommodate an insert bearing. They are strong, stiff and cost-effective, and are suitable for most applications. The housings has threads for attachment bolts so that it can be bolted directly to a support surface.
Additional specs
- Fastening bolt hole type: Threaded
- Housing overall width: 32mm
- Coating: Without
- Grease fitting: With
- Relubrication hole: With
